Alloy Steel Wireline Knuckle Joint 2.5 Inch QLS Connection

Alloy Steel Wireline Knuckle Joint 2.5 Inch QLS Connection

  • Alloy Steel Wireline Knuckle Joint 2.5 Inch QLS Connection
Alloy Steel Wireline Knuckle Joint 2.5 Inch QLS Connection
Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API Q1
Model Number: 1.25inch 1.5inch 1.75inch 1.875inch 2.5inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 1-2 weeks
Payment Terms: T/T
Supply Ability: 1 set 2 weeks
Contact Now
Detailed Product Description
Name: Wireline Knuckle Joint Wireline Tool String Size: 1.25inch 1.5inch 1.75inch 1.875inch 2.5inch
Material: Alloy Steel&Nickel Alloy Fish Neck: 1.187inch 1.375inch 1.75inch 2.313inch
Connection: SR,QLS,BLQJ,HDQRJ Use: Wireline &Slickline
Advantage: Add Flexibility To The Tool String
High Light:

Alloy Steel Wireline Knuckle Joint

,

Wireline Knuckle Joint 2.5 Inch

,

QLS Connection Wireline Knuckle Joint

High Flexibility Wireline Knuckle Joint Wireline Tool String



Wireline Knuckle Joint Wireline Tool String



Ⅰ. Overview:
The universal joint is a wire tool accessory used to provide bending for the tool string.
Because the weighting rod and the jar cannot adjust the bending degree, the universal joint can ensure the normal operation of the steel wire.

Ⅱ. General Technical Parameters

Size

Fishing neck

Connection

PN.

1.25"

1.187"

15/16UN

W08-01.07.00

1.5"

1.375"

15/16UN

W08-01.01.00

1.75"

1.375"

15/16UN

W08-01.02.00

1.875"

1.75"

1-1/16UN

W08-01.03.00

2.5"

2.313"

1-9/16UN

W08-01.09.00

Note: More customized parts are available upon request.

III. Structural features and use:

The universal joint is a spherical design, which can realize the angle deflection between the jar and the fishing tool to facilitate the adjustment of the tool string and the tubing inclination direction, especially when the wire operation is carried out in the curved tubing and directional wells. , The universal joint is essential.

IV. Matters needing attention:
1. The universal joint is often connected below the jar.
2. When the universal joint is not used as a steering tool, it must be connected above the steering tool.

Welcome to contact us at any time.
