Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API Q1
Model Number: 1.5inch 1.875inch 2inch 2.125inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 2-4weeks
Payment Terms: T/T, Western Union
Supply Ability: 1 set 1 week
Contact Now
Detailed Product Description
Material: Alloy Steel&Nickel Alloy Use: Wireline &Slickline
Fish Neck: 1.187inch 1.5inch 1.75inch 1.875inch 2inch 2.5inch Size: 1.25inch 1.5inch 1.75inch 1.875inch 2inch 2.5inch
Connecton: SR QLS HDQRJ BLQJ Service: Standard&H2S

Lead filled stem Wireline Tool String

  1. Introduction

A lead filled stem is designed to serve one purpose. It provides the weight required to overcome friction and pressure differential within the stuffing box during wireline operations, allowing the tool string to descend into the well.

  1. General Technical Parameters
Size Fishing neck Connection Length PN.
1.25" 1.187" 15/16UN 2ft W03-03.23.00
1.25" 1.187" 15/16UN 3ft W03-03.24.00
1.25" 1.187" 15/16UN 5ft W03-03.25.00
1.5" 1.375" 15/16UN 2ft W03-03.26.00
1.5" 1.375" 15/16UN 3ft W03-03.27.00
1.5" 1.375" 15/16UN 5ft W03-03.28.00
1.75" 1.375" 15/16UN 2ft W03-03.03.00
1.75" 1.375" 15/16UN 3ft W03-03.04.00
1.75" 1.375" 15/16UN 5ft W03-03.05.00
1.875" 1.75" 1-1/16UN 2ft W03-03.29.00
1.875" 1.75" 1-1/16UN 3ft W03-03.30.00
1.875" 1.75" 1-1/16UN 5ft W03-03.13.00
2.125" 1.75" 1-1/16UN 2ft W03-03.31.00
2.125" 1.75" 1-1/16UN 3ft W03-03.32.00
2.125" 1.75" 1-1/16UN 5ft W03-03.33.00
2.5" 2.313" 1-9/16UN 2ft W03-03.34.00
2.5" 2.313" 1-9/16UN 3ft W03-03.35.00
2.5" 2.313" 1-9/16UN 5ft W03-03.36.00


Note. More customized parts are available upon request.

  1. Structure characteristics

A lead filled stem consists of top sub, sleeve, lead and lower sub. Threads, PCE breech lock connector, ball and socket type etc. connection types are optional.
