| Place of Origin: | China Baoji |
| Brand Name: | Ruixin |
| Certification: | API |
| Model Number: | 1.5inch 1.875inch 2.25inch 2.5inch |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Wooden Box |
| Delivery Time: | 1 week |
| Payment Terms: | T/T |
| Supply Ability: | 1 week |
| Name: | Alloy Steel Wireline Tool String Slip Rope Socket QLS | Size: | 1.5inch 1.875inch 2.25inch 2.5inch |
|---|---|---|---|
| Material: | Alloy Steel&Nickel Alloy | FN: | 1.187~1.75inch |
| Connection: | SR,QLS,BLQJ,HDQRJ | Application: | Slickline& Wireline |
| Advantage: | Simple& Low Maintenance Design | ||
| High Light: | Alloy Steel Rope Socket Wireline,Rope Socket Slickline Tool String,Slip Rope Socket Wireline Tool String |
||
Alloy Steel Wireline Tool String Slip Rope Socket QLS
I. Overview:
Slip Rope Socket plays the role of connecting cable and downhole instrument, and its upper load-bearing part, lower part is lead part, and the top has fishing neck.
II.the common specifications and technical parameters:
| Size | Applicable tubing | Fishing neck | Connection | PN |
| 1.5＂ | 2-3/8＂～2-7/8＂ | 1.375＂ | 15/16UN | W*0-*0.*0.*0 |
| 1.875＂ | 2-7/8＂～3-1/2＂ | 1.75＂ | 1-1/16UN | W*0-*0.*0.*0 |
| 2.25＂ | 3-1/2＂～4-1/2＂ | 1.75＂ | 1-1/16UN | W*0-*0.*0.*0 |
| 2.5＂ | 4-1/2＂以上 | 2.313＂ | 1-9/16UN | W*0-*0.*0.*0 |
Note: we can supply special specifications according to client's requirements.
III.the use method:
1. firstly, a steel wire rope passes through a rope cap body, slips and a cone;
2. Make a knot in the head of the wire rope;
3. Tighten the top screw and install the slips and weak slips;
4. Lift the wire rope, and install the slips, weak slips and cones into the rope cap body at one time;
5. Connect the lower joint at the body.
IV. Maintenance:
1. Regularly replace check card tile and weak slip with or without damage and deformation;
2. After the wire rope is used for a period of time, the head should be cut off and the rope cap should be made again to avoid the end of the wire rope from being broken due to excessive fatigue.
