Sand Pump Bailer Wireline Tool String
Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API Q1
Model Number: 1.5inch -4.5inch.
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 1-2 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1 set 2 weeks
Contact Now
Detailed Product Description
Name: Sand Pump Bailer Wireline Tool String Material: Alloy Steel&Nickel Alloy
Size: 1.5inch~4.5inch Fish Neck: 1.187inch 1.375inch 1.75inch 2.313inch
Connection: SR,QLS,BLQJ,HDQRJ Use: Wireline &Slickline
Advantage: Clear Debris Which Has Settled On Top Of The Subsurface Equipment Preventing Recovery Of The Equipment By Regular Wireline Operations

Sand Pump Bailer Wireline Tool String

I. Introduction: (B)

A sand pump bailer is a wireline service tool used to clear debris which has settled on top of the subsurface equipment preventing recovery of the equipment by regular wireline operations.The sand pump bailer is a pump type tool which operates on the conventional lift pump and piston principle.

A double male adapter sub an extension bailer tube are available as optional extras in the event of large volume bailing operations

II. General Technical Parameters (A)

Size Fishing neck Connection PN
1.5" 1.375" 15/16UN W24-01.01.00
1.75" 1.375" 15/16UN W24-01.08.00
1.875" 1.75" 1-1/16UN W24-01.07.00
2.0" 1.75" 1-1/16UN W24-01.09.00
2.5" 2.313" 1-1/16UN W24-01.10.00
3.0" 2.313" 1-1/16UN W24-01.11.00
3.5" 2.313" 1-1/16UN W24-01.12.00
4.0" 2.313" 1-1/16UN W24-01.13.00
4.5" 2.313" 1-1/16UN W24-01.14.00

Note. More customized parts are available upon request

III. Structural features: (C)

The sand pump bailer is composed of upper contact, fishing neck, piston rod, barrel, connector (piece 5), lifting rod, piston, pipe shoe, cylindrical pin, steel ball, seal ring, set screw, etc. See the concrete structure in the figure.

When operating it, lift the upper contact and then the piston rod and piston connected with it will move upward. At this moment, the steel ball also will move upward and the rock waste in the well will be sucked up; when lowering the upper contact, the steel ball will fall in the hole of pipe shoe, and the rock waste sucked up will be blocked by the steel ball and kept in the barrel; suck and release it repeatedly until the barrel is filled up with rock waste, and then take out the tool.

The cylindrical pin plays a role of blocking the upward movement of steel ball.

IV.  Maintenance:

1. While using, clear the rock sand in time and clean the interior of barrel.

2. When the tool is not used temporarily, paint the top threads with sealing grease and keep it with thread protector, and paint barrel with lubricating oil for rust protection.
