Innovation Excellence
 |
| Place of Origin: | China Baoji |
| Brand Name: | Ruixin |
| Certification: | API Q1 |
| Model Number: | 1.5inch 1.875inch 2.125inch 2.5inch |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Wooden Box |
| Delivery Time: | 3-4 weeks |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1 set 3 weeks |
| Name: | Flat Bottomed Type GO Devil Wireline Fishing Tool | Size: | 1.5inch 1.875inch 2.125inch 2.5inch |
|---|---|---|---|
| Material: | Alloy Steel | Use: | Wireline &Slickline |
| Fish Neck: | 1.187inch 1.375inch 1.75inch 2.313inch | Length: | 2ft 3ft 5ft |
| Service: | Standard &H2S | ||
| High Light: | 5ft Slickline Fishing Tools,Flat Bottomed Wireline Overshot,Alloy Steel Slickline Overshot |
||
Flat Bottomed Type GO Devil Wireline Fishing Tool
I. Overview:
The Flat Bottomed Type GO Devil is used to cut the stuck tool string wire.
The Flat Bottomed Type GO Devil is composed of a solid rod with a groove and a guide surface. It goes into the well in a conventional way. If there is no foreign matter on the rope cap, the inclined plane of the cutter will directly cut the steel wire on the rope cap. When the steel wire tool is seriously buried by sand, debris or steel wire, or it is not cut at one time. It can be struck again with a flat-bottomed wire cutter.
The steel wire cutter is provided with a positioning groove for installing the slip centralizer, which can be used in large diameter oil pipes after installing the slip centralizer.
II, the commonly used technical parameters:
| Size | Fishing neck | length | Applicable steel wire specification |
| 1.5＂ | 1.375＂ | 2ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 1.5＂ | 1.375＂ | 3ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 1.5＂ | 1.375＂ | 5ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 1.875＂ | 1.75＂ | 2ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 1.875＂ | 1.75＂ | 3ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 1.875＂ | 1.75＂ | 5ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 2.125＂ | 1.75＂ | 2ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 2.125＂ | 1.75＂ | 3ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 2.125＂ | 1.75＂ | 5ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 2.5＂ | 2.313＂ | 2ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 2.5＂ | 2.313＂ | 3ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
| 2.5＂ | 2.313＂ | 5ft | 0.092＂～0.108＂/7/32＂～3/16＂ |
III. Structural characteristics and use:
The Flat Bottomed Type GO Devil is composed of a grooved inclined-bottom solid rod and a baffle. The baffle is connected with the grooved solid rod by screws. When in use, the baffle is removed, the steel wire is clamped into the groove, and then the baffle is installed. The steel wire cutter runs down the steel wire into the well and cuts the steel wire at the head of the rope cap. Then, the wire cutter and tool string are fished out with a fishing device.
IV. Precautions:
When using the inclined bottom wire cutter, make sure there is no foreign matter above the rope cap. Otherwise it cannot cut the steel wire. Secondly, after using the inclined bottom wire cutter, timely and carefully maintain it to prolong the service life of the tool.
