API Slickline Fishing Tools 3-1/2 Tubing Perforator

API Slickline Fishing Tools 3-1/2 Tubing Perforator

  • API Slickline Fishing Tools 3-1/2 Tubing Perforator
API Slickline Fishing Tools 3-1/2 Tubing Perforator
Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API Q1
Model Number: 2-3/8 Tubing/2-7/8 Tubing/3-1/2 Tubing
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 3-4 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1 set 2 weeks
Contact Now
Detailed Product Description
Name: 3-1/2 Tubing Perforator Slickline Fishing Tools Size: 3-1/2 Tubing
Fish Neck: 2.313inch Connection: 1-1/16-10UN
Material: Alloy Steel&Nickel Alloy Function: To Perforate Standard And Heavy Wall Tubing Under Pressure
Highlight:

Tubing Perforator Fishing Tool

,

Slickline Tubing Punch Tool

,

3.5 Inch Wireline Overshot



3-1/2 Tubing Perforator Slickline Fishing Tools

I. Overview:
The punch in the Tubing Perforator Slickline Fishing Tools is seated in the conical wedge groove. After the tool is lowered to the predetermined depth of the tubing and seated, the shear pin is gently shaken down, and then lifted up, following the conical wedge. Ascending, the punch is squeezed out and the tubing is punched through. After half of the stroke of the tapered wedge, the punch is started to be retracted, and then the punch is lifted up and the tool is taken out.
II.Technical parameters:

Specification Salvage neck  connection thread PN
2-3/8 Tubing 1.375＂ 15/16-10UN W0*-0*.0*.00
2-7/8 Tubing 1.375＂ 15/16-10UN W0*-0*.0*.00
3-1/2 Tubing 2.313＂ 1-1/16-10UN W0*-0*.0*.00
III. Structural features and use:
The Tubing Perforator Punch is able to punch holes in downhole tubing. The blasting method is not used when the tool is used, which eliminates the possibility of shooting through the casing; the safety release mechanism can take out the perforator when it is not perforated without any danger; it has strong tubing penetration ability; it can automatically shrink after perforation Back punch and release automatically.
A-type tubing piercer is generally only suitable for ordinary tubing piercing. When in use, the weight of the weighting rod is generally 13-15kg. When piercing, it does not need a strong upward shock.

IV, matters needing attention:
1. Before drilling, check the material of the tubing. The tubing with a softer material is not suitable for drilling with a mechanical punch.
2. Replace damaged parts in time.

Tools Can Be Manufactured To Any Size Required. Welcome to contact us at any time.

API Slickline Fishing Tools 3-1/2 Tubing Perforator 0
