| Name: | 3 Inch Wireline Tubing Broach Gauge Cutter Wireline | Size: | 1 Inch ~6 Inch |
|---|---|---|---|
| Fish Neck: | 1.187inch 1.375inch 1.75inch 2.313inch,3.125inch | Material: | Alloy Steel&Nickel Alloy |
| Application: | Slickline& Wireline | Advantage: | Is Also Used To Remove Scale, Rust Etc |
| High Light: | Nickel Alloy Tubing Broach,Gauge Cutter Wireline Tubing Broach,3 Inch Wireline Broach Cutter |
||
3 Inch Nickel Alloy Wireline Tubing Broach For Remove Rust
Wireline Tubing Broach Gauge Cutter Wireline
I. Overview:
The conical scraper is a tool used to hang any natural obstruction cone in the well or to reshape the tubing with a small amount of deformation. The whole cone can hang up the obstruction of about 4mm.
The Tubing Broach is used to remove burrs in the tubing left after perforating and broaching through the restrictions in the tubing. Tubing Broach is also used to remove scale, rust etc, from tubing I.D.
II. Product Specifications:
| Max. O.D. (in) | F/N. O.D.(in) | Top Connection |
|---|---|---|
| 1.50 | 1.375 | 15/16 - 10 UN |
| 2.00 | 1.375 | 15/16 - 10 UN |
| 2.50 | 1.375 | 15/16 - 10 UN |
| 3.00 | 1.750 | 1-1/16 - 10 UN |
| 4.00 | 1.750 | 1-1/16 - 10 UN |
| 5.00 | 2.313 | 1-1/16 - 10 UN |
Conical scrapers are available in various specifications according to customer requirements.
III. Structural characteristics:
The oil pipe shaper is connected by the main body, the scraper and the pressure cap. After the pressure cap is connected with the main body, it is supported by nails (see the attached picture for the specific structure).
There is a vent hole on the body, which is used for venting or draining liquid during use, so as to prevent any end from being held back, causing difficulty in use or accidents.
The scraper is a shuttle type with small ends and a large middle, which is used to scrape obstacles up and down the shock cone, and can scrape downward or upward.
