Place of Origin: | China Baoji |
Brand Name: | Ruixin |
Certification: | API Q1 |
Model Number: | 1.25inch-2.5inch |
Minimum Order Quantity: | 1 |
---|---|
Packaging Details: | Wooden Box |
Delivery Time: | 2-4 weeks |
Payment Terms: | T/T, Western Union |
Supply Ability: | 1 set 2 weeks |
Name: | Wireline PCE Stem Weight Bar Wireline Tool String | Size: | 1.25inch-2.5inch |
---|---|---|---|
Material: | Alloy Steel&Nickel Alloy | Use: | Wireline &Slickline |
Fish Neck: | 1,187inch~2.313inch | Connection: | SR QLS HDQRJ, BLQJ |
Service: | Standard&H2S | ||
Highlight: | Weight Bar Wireline Tool String,Stem Bar Wireline Tool String,Wireline Stem Weight Bar |
Nickel Alloy Wireline PCE Stem Weight Bar Wireline Tool String for Oil Well
Wireline PCE Stem Weight Bar Wireline Tool String
Ⅰ. Introduction (B)
A wireline Pce stem weight bar is designed to serve two purposes. Firstly it is the weight required to overcome forces created by well pressure and the size of cable used and secondly it is the mass required to deliver impacts when setting or pulling devices in the wellbore.
The stem is cylindrical with fishing neck and pin connection (or QRJ pin) on the top and with box connection (or QRJ box) on the bottom.
Ⅱ. General Technical Parameters (A)
Size | Fishing neck | Connection | Length | PN. |
1.25" | 1.187" | 15/16UN | 2ft | W03-01.03 |
1.25" | 1.187" | 15/16UN | 3ft | W03-01.04 |
1.25" | 1.187" | 15/16UN | 5ft | W03-01.27 |
1.5" | 1.375" | 15/16UN | 2ft | W03-01.08 |
1.5" | 1.375" | 15/16UN | 3ft | W03-01.06 |
1.5" | 1.375" | 15/16UN | 5ft | W03-01.07 |
1.75" | 1.375" | 15/16UN | 2ft | W03-01.24 |
1.75" | 1.375" | 15/16UN | 3ft | W03-01.25 |
1.75" | 1.375" | 15/16UN | 5ft | W03-01.11 |
1.875" | 1.75" | 1-1/16UN | 2ft | W03-01.08 |
1.875" | 1.75" | 1-1/16UN | 3ft | W03-01.09 |
1.875" | 1.75" | 1-1/16UN | 5ft | W03-01.10 |
2.125" | 1.75" | 1-1/16UN | 2ft | W03-01.28 |
2.125" | 1.75" | 1-1/16UN | 3ft | W03-01.29 |
2.125" | 1.75" | 1-1/16UN | 5ft | W03-01.30 |
2.5" | 2.313" | 1-9/16UN | 2ft | W03-01.31 |
2.5" | 2.313" | 1-9/16UN | 3ft | W03-01.32 |
2.5" | 2.313" | 1-9/16UN | 5ft | W03-01.33 |
Note. More customized parts are available upon request.
Ⅲ. Structural features (C)
The wireline Pce stem weight bar is the most frequently-used model with advantages of simple design and easy operation.
Ⅳ. Notes
1. Standardstem is the simplest and commonly used weight stem. During usage, the thread in both ends require firm connection. It is necessary to choose appropriate weight stem during operation according to practical condition.
2. After using standard stem, please keep in good repair for extending its service life.
