2.125"Tubular Jar Wireline Tool String Nickel Alloy

2.125"Tubular Jar Wireline Tool String Nickel Alloy

  • 2.125"Tubular Jar Wireline Tool String Nickel Alloy
  • 2.125"Tubular Jar Wireline Tool String Nickel Alloy
2.125"Tubular Jar Wireline Tool String Nickel Alloy
Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API Q1
Model Number: 1.25inch 1.5inch 1.875inch 2.125inch 2.5inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 3-4 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1 set 3 weeks
Contact Now
Detailed Product Description
Name: 2.125 Inch Tubular Jar Wireline Tool String Size: 1.25inch 1.5inch 1.875inch 2.125inch 2.5inch
Fish Neck: 1.187inch 1.375inch 1.75inch 2.313inch Material: Alloy Steel&Nickel Alloy
Stroke: 20inch 24inch 30inch Service: Standard&H2S
Connection: SR QLS HDQRJ, BLQJ Working Condition: Standard
Highlight:

Tubular Jar Wireline Tool String

,

Wireline Tubular Jar

,

2.125"Wireline Tool String

2.125"Tubular Jar Wireline Tool String Nickel Alloy



Tubular Jar Wireline Tool String

I.Introduction

The Tubular Jar is designed to enable the operator to deliver effective jarring forces in conjunction with wireline running tools,and other devices.

Tubular Jar is primarily used for providing a bi-directional mechanical jar action in situations where there may be the potential for debris ingress.

II.General Technical Parameters

2.125"Tubular Jar Wireline Tool String Nickel Alloy 0

Technical Parameters of general specification recommended displacement tubular jar are shown below:

Size

Fishing neck

Connection

Stroke

1.25"

1.187"

15/16-10UN

20"

1.25"

1.187"

15/16-10UN

24"

1.5"

1.375"

15/16-10UN

20"

1.5"

1.375"

15/16-10UN

24"

1.5"

1.375"

15/16-10UN

30"

1.875"

1.75"

1-1/16-10UN

20"

1.875"

1.75"

1-1/16-10UN

24"

1.875"

1.75"

1-1/16-10UN

30"

2.125"

1.75"

1-1/16-10UN

20"

2.125"

1.75"

1-1/16-10UN

24"

2.125"

1.75"

1-1/16-10UN

30"

2.5"

2.313"

1-9/16-10UN

20"

2.5"

2.313"

1-9/16-10UN

24"

2.5"

2.313"

1-9/16-10UN

30"

III.Use

Typically used in fishing scenarios where parted wire is present within the tubing, Tubular Jar can also be used during swabbing operations to bear the high loading or in large ID well bores where mechanical type ‘spang’ jars are prone to scissoring.

Note. Tools can be manufactured to any size required.

Welcome to contact us at any time.

2.125"Tubular Jar Wireline Tool String Nickel Alloy 1

About Baoji RuiXin Slickline Tools

Baoji Ruixin Energy Equipment Co., Ltd. was established in 2012. It is an IS0: 9001-2015 and API Q1 system certified technology research and development organization specializing in the design and manufacture of steel wire, cable and coiled tubing tools. With strong new product research and development capabilities, it has obtained 12 national utility model patent certificates and 1 invention patent certificate. Undertook two prefecture-level and provincial-level scientific research projects. Our products include wireline wireline wellhead blowout prevention equipment, wireline downhole tools and coiled tubing downhole tools. At present, we have provided professional equipment and technical support to more than 50 oilfield service companies in various regions at home and abroad.

Strict quality control system

Steel wire working tools are certified by API, and all manufacturing are strictly in accordance with API system, including quality control management, environmental management and occupational health and safety management. For each wire working tool and each part, we have achieved traceability from raw materials, production process to product shipment.

Hard work, after-sales service

On-site technical guidance exchanges with each other. Our sales and technical personnel communicated well with front-line engineers and technical experts on the job site, and solved technical problems such as material selection, sealing structure optimization, and accident handling in complex environments. And carried out many technical exchanges and friendly cooperation. We have done a good job of product after-sales service for customers, and we provide customers with more satisfactory services. We would like to thank more and more customers for their support and trust. In the future, we will do better.
