|Place of Origin:||China Baoji|
|Minimum Order Quantity:||1|
|Packaging Details:||Wooden Box|
|Delivery Time:||2-3 weeks|
|Payment Terms:||T/T, Western Union|
|Supply Ability:||1 set 2 weeks|
|Name:||3 Inch Tubing Swage Wireline Tool String||Size:||1.25inch~5inch|
|Material:||Alloy Steel&Nickel Alloy||Fish Neck:||1.187inch 1.375inch 1.75inch 2.313inch|
|Connection:||SR,QLS,BLQJ,HDQRJ||Advantage:||Adjust The ID Of The Tubing To Ensure Smooth Passage Of The Tool|
|Use:||Wireline &Slickline||Working Condition:||Standard|
Tubing Swage Wireline Tool String,
2 Inch Wireline Tool String,
45HRC Wireline Tool String
Tubing swage is a tool to shape the changed diameter of to guarantee that the downhole device can pass smoothly or to get through the flavedo-type blocks at the end of tubing.
II. General Technical Parameters
|OD||Fishing neck||Connection t||PN|
Note:more customized parts are available upon request.
III. Structural features:
The top of the tubing swage has external threads (or quick male joint) and fishing neck; the inner diameter
of waist is about equal to that of the deformed oil pipe, so there are air holes or drain holes in the middle,
and the pipe tapers off from the middle to both ends; the bottom also can be processed with threads to connect
The whole body of tubing swage is made of alloy steel, and the hardness of the part for shaping reaches
43～45HRC through quenching and tempering.
