| Place of Origin: | China Baoji |
| Brand Name: | Ruixin |
| Certification: | API Q1 |
| Model Number: | 1.5inch - 3inch |
| Minimum Order Quantity: | 1 |
|---|---|
| Packaging Details: | Wooden Box |
| Delivery Time: | 3-4 weeks |
| Supply Ability: | 1 set 3 weeks |
| Name: | 2 Inch S Type Pulling Tools For Wireline Pulling Tool | Size: | 1.5inch - 3inch |
|---|---|---|---|
| Fish Neck: | 1.187inch 1.375inch 1.75inch 2.313inch | Material: | Alloy Steel&Nickel Alloy |
| Type: | SB SM SS | Connection: | SR,QLS,BLQJ,HDQRJ |
| Grasping Diameter: | 0.875inch 1inch 1.187inch 1.375inch 1.75inch 2.313inch 3.125inch | ||
| Highlight: | S Type Slickline Pulling Tools,BLQJ Connection Slickline Pulling Tools,15/16UN Slickline Pulling Tools |
||
2 Inch S Type Pulling Tools For Wireline Pulling Tool
I. Overview:
The S-type Pulling tool is an external Pulling tool. Its structure principle is similar to the JD type fishing tool, the outer fishing neck is grasped by a special claw, and it can be shaken down to release it. According to the different grip distance, it can be divided into SB and SS.
II. The main technical parameters of the tool:
| Size | Actual outer diameter | Fishing neck | Connection | Grab diameter |
| 1.5＂ | 1.43＂ | 1.187＂ | 15/16UN | 1.187＂ |
| 2＂ | 1.77＂ | 1.375＂ | 15/16UN | 1.375＂ |
| 2.5＂ | 2.18＂ | 1.75＂ | 15/16UN | 1.75＂ |
| 3＂ | 2.74＂ | 2.313＂ | 15/16UN | 2.313＂ |
According to customer's requirements, we can also provide products with required specifications and parameters.
III. salvage operation steps:
1. Connect the fishing tool to the basic tool string and go down the well;
2. When quickly descending to the predetermined position, slowly lower the tool string;
3. Wait for the tool to grab the outer salvage neck and shake upwards;
4. When the upward shock cannot be lifted out, the downward shock can be used to release.
IV. Disposal after the tool is released:
After pulling out the tool, insert the jam-releasing tool or screwdriver into the jam-releasing place, pry open the fishing claw, open the fishing claw, and then release the tool.
V.Matters needing attention:
Before running the tool, check that there is no looseness in the thread of the tool connection.
