2″ Shock Absorber Wireline Pressure Gauge Hanger 15/16-10UN

2″ Shock Absorber Wireline Pressure Gauge Hanger 15/16-10UN

  • 2″ Shock Absorber Wireline Pressure Gauge Hanger 15/16-10UN
2″ Shock Absorber Wireline Pressure Gauge Hanger 15/16-10UN
Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API
Model Number: 2.375inch-5.5inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 3-4 weeks
Payment Terms: T/T
Supply Ability: 1 set 3 weeks
Contact Now
Detailed Product Description
Name: Shock Absorber Wireline Pressure Gauge Hanger Size: 1.25inch-2.5inch
Fishing Neck: 1.187inch-2.3135inch Material: Alloy Steel&Nickel Alloy
Upper Connection: 15/16-10UN Lower Connection: 3/4-16UN
High Light:

2″ Wireline Pressure Gauge Hanger

,

Alloy Steel Wireline Pressure Gauge Hanger

,

Cylindrical Wireline Pressure Gauge Hanger

                                                         Shock Absorber Wireline Pressure Gauge Hanger

I. Overview:
In the wire work, the shock absorber is used to reduce the vibration transmitted to the instrument when running in.
The shock absorber is basically composed of a salvage neck, a cylinder, an auxiliary spring, a mandrel, a main spring, a plug cap, and a lower joint. The main spring is stronger because it has to bear the weight of its lower instrument and is in a constant compression state. The mandrel moves between the springs and absorbs shocks, thereby protecting the downhole state of the instrument.



II. Technical parameters:

 Size  Fishing neck   upper Connection   Lower Connection
 1.25″ 1.187″ 15/16-10UN 3/4-16UN
 1.5″  1.375″ 15/16-10UN 3/4-16UN
 1.75″ 1.375″ 15/16-10UN 3/4-16UN
 1.875″ 1.75″ 15/16-10UN 3/4-16UN
 2″ 1.75″ 15/16-10UN 3/4-16UN
 2.5″ 2.313″ 15/16-10UN 3/4-16UN



III. Structural features and use:

The shock absorber is mainly composed of a salvage neck, a cylinder, an auxiliary spring, a mandrel, a main spring, a plug cap, a lower joint, etc. The specific structure is shown in the attached drawings.
When going down the well, the tool string is connected, and the lower part is connected to the instrument. The mandrel of the shock absorber moves between the two springs and absorbs the shock, so as to protect the downhole state of the instrument.
IV, matters needing attention:
1. When using, carefully check whether the parts are well connected and whether the mandrel can be moved, in case the shock absorber cannot be used after going down the well.
2. When not in use temporarily, apply lubricating oil to the thread and place it with a protective wire.

Welcome to contact us at any time.
