2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard

2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard

  • 2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard
  • 2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard
2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard
Product Details:
Place of Origin: China Baoji
Brand Name: Ruixin
Certification: API Q1
Model Number: 2.375inch 2.5inch 3.5inch
Payment & Shipping Terms:
Minimum Order Quantity: 1
Packaging Details: Wooden Box
Delivery Time: 3-4 weeks
Payment Terms: T/T, Western Union
Supply Ability: 1 set 3 weeks
Contact Now
Detailed Product Description
Name: 2.5"Swab Tool Wireline Tool String Size: 2.375inch 2.5inch 3.5inch
Fish Neck: 1.375inch 1.75inch Material: Alloy Steel&Nickel Alloy
Service: Standard&H2S Connection: SR QLS HDQRJ, BLQJ
Working Condition: Standard
High Light:

Nickel Alloy Wireline Swab Tool


2.5" Swab Tool


Swab Wireline Tool String

2.5"Swab Tool Wireline Tool String Nickel Alloy



The swab tool is a tool used to extract fluid from the well and can be used repeatedly. Swabbing tool is the use of a special pump, through the wire rope down the well up and down repeated activities, the pump when the pump above the liquid out of the wellhead, while the use of the lower part of the pump to produce low pressure, so that the liquid in the oil reservoir continuously replenished to the well.

II.General Technical Parameters

Size Fishing neck Connection PN
2.375" 1.375" 15/16-10UN W*0-*0.*0.00
2.5" 1.75" 1-1/16-10UN W*0-*0.*0.00
3.5" 2.313" 1-9/16-10UN W*0-*0.*0.00

Any size can be customized according to customer needs

2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard 0


Swabbing tool In oil field production, the commonly used pumps include two-lobe pumps and hydraulic pumps. The main structure of the hydraulic pump is composed of a rubber cylinder, a center pipe, a ball valve and a seat. The pump goes down the well with the cable, and under the action of gravity, the pump goes down the wall of the pipe. The ball valve opens under the impact of the fluid, which flows up the center pipe. After the pump is in place, the cable is lifted up, and the ball valve is closed under the action of gravity. The liquid weight on the upper part of the pump acts on the whole pump, and the rubber cylinder is squeezed to seal it. The liquid goes up with the pump to complete a suction. The fluid is pumped to the surface several times.


2.5" Swab Tool Nickel Alloy Material Wireline Tool String Standard 1

Welcome to contact us at any time.


About Baoji RuiXin Slickline Tools

Baoji Ruixin Energy Equipment Co., Ltd. was established in 2012. It is an IS0: 9001-2015 and API Q1 system certified technology research and development organization specializing in the design and manufacture of steel wire, cable and coiled tubing tools. With strong new product research and development capabilities, it has obtained 12 national utility model patent certificates and 1 invention patent certificate. Undertook two prefecture-level and provincial-level scientific research projects. Our products include wireline wireline wellhead blowout prevention equipment, wireline downhole tools and coiled tubing downhole tools. At present, we have provided professional equipment and technical support to more than 50 oilfield service companies in various regions at home and abroad.

Strict quality control system

Steel wire working tools are certified by API, and all manufacturing are strictly in accordance with API system, including quality control management, environmental management and occupational health and safety management. For each wire working tool and each part, we have achieved traceability from raw materials, production process to product shipment.

Hard work, after-sales service

On-site technical guidance exchanges with each other. Our sales and technical personnel communicated well with front-line engineers and technical experts on the job site, and solved technical problems such as material selection, sealing structure optimization, and accident handling in complex environments. And carried out many technical exchanges and friendly cooperation. We have done a good job of product after-sales service for customers, and we provide customers with more satisfactory services. We would like to thank more and more customers for their support and trust. In the future, we will do better.
