Innovation Excellence
 |
| Place of Origin: | China Baoji |
| Brand Name: | Ruixin |
| Certification: | API Q1 |
| Model Number: | 2-3/8 Tubing~4-1/2Tubing |
| Minimum Order Quantity: | 1 |
|---|---|
| Price: | USD 1800~ |
| Packaging Details: | Wooden Box |
| Delivery Time: | 3-4 weeks |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 1 set 3 weeks |
| Name: | Tubing Perforator Wireline Pulling Tool | Material: | Alloy Steel&Nickel Alloy |
|---|---|---|---|
| Size: | 2-3/8 Tubing~4-1/2Tubing | Fish Neck: | 1.375inch 1.75inch 2.313inch |
| Body O.D: | 1.84inch 2.19inch 2.69inch 3.65inch | Function: | To Perforate Standard And Heavy Wall Tubing Under Pressure |
| Connection: | SR,QLS,BLQJ,HDQRJ | ||
| High Light: | Wireline Pulling Tubing Perforator,Wireline Pulling Tool 2-7/8inch,Nickel Alloy Tubing Perforator |
||
Tubing Perforator Wireline Pulling Tool
Ⅰ. Introduction
The Tubing Perforator (tubing punch) is a mechanical device designed to perforate standard and heavy wall tubing under pressure.The tubing perforators are available for tubing size 2-3/8 Tubing through 4-1/2 Tubing.
Ⅱ. Specification
|
Tubing Size |
F. N. |
Connection |
PN. |
|
2-3/8Tubing |
1.375＂ |
15/16UN |
W0*-0*.0*.00 |
|
2-7/8Tubing |
1.375＂ |
15/16UN |
W0*-0*.0*.00 |
|
3-1/2Tubing |
2.313＂ |
1-1/16UN |
W0*-0*.0*.00 |
|
4-1/2Tubing |
2.313＂ |
1-1/16UN |
W0*-0*.0*.00 |
III. Structural features
The Tubing Perforator is able to punch holes in downhole tubing. It is used to aid in the draining of fluid from the tubing when the tubing needs to be removed from the well. It can also be used as a method to allow communication between the tubing and casing for injection of chemicals or to circulate kill fluid. Another use is to allow additional productive zones to be introduced to the production string when permitted.
Welcome to contact us at any time.
◆About Baoji RuiXin Slickline Tools
Baoji Ruixin Energy Equipment Co., Ltd. was established in 2012. It is an IS0: 9001-2015 and API Q1 system certified technology research and development organization specializing in the design and manufacture of steel wire, cable and coiled tubing tools. With strong new product research and development capabilities, it has obtained 12 national utility model patent certificates and 1 invention patent certificate. Undertook two prefecture-level and provincial-level scientific research projects. Our products include wireline wireline wellhead blowout prevention equipment, wireline downhole tools and coiled tubing downhole tools. At present, we have provided professional equipment and technical support to more than 50 oilfield service companies in various regions at home and abroad.
◆Strict quality control system
Steel wire working tools are certified by API, and all manufacturing are strictly in accordance with API system, including quality control management, environmental management and occupational health and safety management. For each wire working tool and each part, we have achieved traceability from raw materials, production process to product shipment.
◆Hard work, after-sales service
On-site technical guidance exchanges with each other. Our sales and technical personnel communicated well with front-line engineers and technical experts on the job site, and solved technical problems such as material selection, sealing structure optimization, and accident handling in complex environments. And carried out many technical exchanges and friendly cooperation. We have done a good job of product after-sales service for customers, and we provide customers with more satisfactory services. We would like to thank more and more customers for their support and trust. In the future, we will do better.
